Product Description
The Ultimate All-In-One Multi-Cam Live Streaming & Switching System
More Inputs, Bigger & Brighter Display, Enhanced Performance
- 3 x HDMI, 1 x USB In, 1 x SD card, 1 x PDF; 1 x HDMI out; 1 x SIM card; 1x USB-C output; Mic-in/Line-in;
- Live switch up to 8 sources
- Direct integration with YouTube/Facebook/RTMP(s)
- Built-in simultaneously streaming
- Stream via Ethernet, Wi-Fi, LTE 4G
- Import pictures/videos from SD card
- Add logos/watermarks/rolling captions to the stream
- Feature comment overlays to the Stream
- Add and edit customizable scoreboard, built-in lower-thirds
- Load PDF as an extra source locally
- Records internally to SD card
- Built-In Chroma Key
- Audio Mixer
YoloBox Pro COMPLETE Tour - All-in-one Live Streaming + Switching with Green Screen, PiP, Graphics
YoloBox Pro Review! The Easiest Way to Get Live Streaming in 2021?
YoloBox vs YoloBox Pro: Current & Upcoming New Features

Stream Simultaneously to Multiple Destinations
Stream to Facebook, YouTube, and any other RTMP(S) websites at the same time to get more views

Add 2 Video Sources From Local SD Card

Load PDF as an Extra Source Locally
Enhance the storytelling by one extra source.
Audio Mixer

Built-in Chroma Key

Brand Your Live Stream By Adding Logos/Watermarks/Rolling Captions

Feature Comment Overlays to the Stream

Add Customizable Scoreboard

Add and Edit on the Built-In Lower-Thirds Templates

Specifications
Dimensions & Weight
- Height: 27mm
- Width: 129mm
- Length: 218mm
- Weight: 750g
Ports
- HDMI IN: Video input
- USB IN: Video input
- (Please note in some usb webcams, only video can be captured.)
- HDMI OUT: Video input
- Ethernet: Connect to Internet by Ethernet cable
- AUDIO IN: Connect with lavalier microphone or mixer
- TYPE-C 3.0: A fully functional interface supports input/output
- TYPE-C: Power connector
- LINE IN: Stereo, connect to electric guitar or synthesizer
- MIC IN: Mono, connect to microphone for recording
- AUDIO OUT: Connect with headphone for sound monitor
- Sim Card Slot: Insert SIM Card to get into Internet
- HOTSHOE: Mount YoloBox with camera
- SD Card: Insert SD card for local assets
- Power Button: Turn on and turn off
Encoded Format
- Video Encoded Format:H.264
- Audio Encoded Format:AAC (44.1k)
- Video Recorded format:MP4
- Audio Input Format:32kHz/44.1kHz/48kHz/16-bit/16kHz
- Video Input Format:1080i/ 720p/ 1080p
- Live Broadcast Resolution:540P/720P/1080P
Video Storage
- Storage Card Type:SD Card
- Storage Card Capacity:Expanded to 128G in FAT32, exFAT, NTFS format
Network Connection
- WiFi:2.4G/5G
- 4G Network Countries & Frequency Band For
- Users:[NA:Variant for North America(US/Canada/Mexico)]
- B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B66/B71
- Notes:Mexico B4
- For Non-US/Canada/Mexico Users:(EM:Variant for EMEA/India/Korea/Taiwan/South
- Asia/Latin America/Australia/New Zealand)Users:
- B1/B2/B3/B4/B5/B7/B8/B20/B28/B38/B39/B40/B41
- Notes:Thailand B7
- Please note that the Yolobox complete machine certification corresponds to the mainstream frequencies and wavelengths of the local mainstream telecom operators.
- SIM Card Size:Nano card
Power
- Power Interface:Type C, Quick Charge 3.0
- Battery Capacity:10000mAh
- Rated Voltage: 5V-3A; 9V-2A; 12V-1.5A
- Transmission
- Network Protocol:RTMP(S)
Working Environment
- Operating Temperature:-10℃-40℃
- Storage Temperature:5℃-40℃
